VL-50-B/50S-BOptionalaccessoriesOptionalweightsfortheLitematic02AZE375OneofthenotablecharacteristicsoftheLitematicisitssmallmeasuringforce(0.01Nor0.15Nmodels).However,dependingonthecharacteristicsoftheworkpiece,itmaynotbepossibletotransmitasufficientmeasuringforceandthecontactpointmayappearsuspended.Tosolvesuchaproblem,optionalweightsareavailablethatattachtothespindletoachievetheappropriatemeasuringforcewithoutdamagingtheworkpiece.Note:CannotbeusedwithVL-50-100-B,orVL-50S-100-BSpindlewithanoptionalweightinstalledExternalappearanceofoptionalweightsWeightB(approximately20gf)WeightC(approximately10gf)WeightA(approximately40gf)Extensionrod(approximately5gf)Measuringforcesgeneratedbyweightcombinationsfor0.01/0.15NmodelsMeasuringforce(N)0.010.060.160.260.360.460.560.660.760.860.960.150.210.310.410.510.610.710.810.91̶̶ExtensionrodABC1111111111111111112211111PrinterandconnectingcableDigimaticminiprocessorDP-1VALOGGER264-505**TodenoteyourAClinevoltageaddthefollowingsuffixes.AforNorthAmerica,DforEurope,EforUK,KforKorea,DCforChina,BforOceaniawithoutACadapterandnosuffixisrequiredforJapan.PrintstheDigimaticoutputupto8digitsfromLitematic.•Connectingcable(1m)936937Note:ThenumberofsignificantdigitsforDigimaticoutputissix.4-5
| <
|
> |
>>
